  Security and Service functions

• Two remote controls.
• 433.92 MHz working frequency.
• One 5-button LCD remote control.
• One 4-button slim remote control.
• Learning Code.
• Control range: up to 300 meters.
• Range of paging: 800 meters.
• 2-level shock sensor included
• ARM / DISARM by separate buttons of remote control.
• Locking / Unlocking the doors.
• Management locks the doors when IGN ON / OFF.
• Silent ARM.
• ARM / DISARM without siren chirps.
• Trunk opener relay inside.
• ALARM mode.
• SEARCH mode.
• VALET mode.
• Anti-Hi-Jack mode.
• Check Status.
• Built-in relays for central locking.
• Built-in parking lights relay.
• Dome light delay.
• Blocking engine output.
• Blocking relay in complete kit.
• Negative door switch input.
• Positive door switch input.
• TURBOTIMER.
• Notify about defective zone.
• Defective zone bypass.
• Two level shock sensor in complete kit.
• Compact antenna module.
• Pin switch in complete kit.

  Additional channels

• Channel №1
    - 200 mA output. NC blocking engine

• Channel №2
    - 200 mA output. Turbotimer output

• Channel №3
    - 20 A output. Trunk opener.

  Electrical parameters

Power supply: 9-15 V DC
Current consumption: 15 mA
Operating temperature range -30° C ... + 75° C
The maximum allowable current connections:
        -external blocking engine relay: 30 A
         - parking lights relay: 10A
         - central door lock relays: 15A
Battery type of LCD remote is AAA 1.5V
Pneumatic/Electrical door lock type
Dome light delay 20 sec.
